It's all in the details. Meticulous columns grace the motor housing to create a sophisticated, timeless look making the Ainsworth the ideal centerpiece for your french country decor style. Drawing inspiration from ornamental design in classic architectural sheet metal, the Ainsworth boasts a traditional style with a simple, yet tasteful touch for a truly distinguished look.
Energy Information at High Speed
Airflow:
3431 Cubic Feet per Minute
Electricity Rate:
46 Watts (excluded lights)
Airflow Efficiency:
74 Cubic Feet Per Minute Per Watt
Standard Information
Category:
Fans
Subcategory:
Ceiling Fans
Voltage:
100-120
Number of Blades:
5 Blades
Refinement Options
Category:
Fan
Finish:
Cottage White
Style:
Traditional
Option:
ETL Approved
Family:
Ainsworth
Voltage:
120 V/60 Hz
Air Flow CFM:
3431
Air Flow Efficiency:
74
Amperage:
0.66
Blade Finish:
Cottage White
Blade Pitch:
13
Blade Span:
54
Blades Included:
Yes
Canopy:
Height- 2.75, Width- 6.49
Designer:
Ainsworth
Down Rod Included:
2
3
Electricity Used:
46
Light Kit Included:
No
Motor Fan Speed:
4
Motor RPM:
174
Motor Size:
172 x 20
Motor Type:
Direct Drive
Pull Chain Included:
Yes
Ship Carton Height:
9.5
Ship Carton Length:
13.9
Ship Carton Width:
21.3
Ship Weight:
24.2
Sold By:
EA
Warranty:
Limited Lifetime Motor Warranty
Weight:
20.56
6 Square (ID):
Formal Traditional
Airflow:
3431
Amps High:
0.66
Amps Low:
0.16
Amps Medium:
0.49
Batteries Included:
No
Blade Material:
Plywood
Blade Overlay:
Veneer
Blade Pitch Feature:
13 degree blade pitch optimized to ensure ideal air movement and peak performance
Blade Side 1 Finish:
Cottage White
Blade Side 2 Finish:
Cottage White
Blade Side Feature:
5 Cottage White blades included
Bulb Included:
No
Can be used without Lightkits:
No
Canopy Mounting Feature:
Installer's Choice® three-position mounting system allows for standard, low, or angled mounting
Canopy Type Description:
Standard Platform
Carton Cubic Feet:
1.63
Ceiling to Bottom of Fan:
46.1
CFM High:
6017
CFM Low:
1502
CFM Medium:
4931
Country of Origin:
CN
Dim A - Angled - Ceiling to Bottom of Fan:
46.1
Dim A - Standard - Ceiling to Bottom of Fan:
13.11
Dim A Angled Ceiling To Bottom Of Fan:
46.10
Dim A Flush Ceiling To Bottom Of Fan:
12.11
Dim A Standard Ceiling To Bottom Of Fan:
13.11
Dim B - Angled - Ceiling to Bottom of Fan Blade:
44.73
Dim B - Flush - Ceiling to Bottom of Fan Blade:
10.73
Dim B - Standard - Ceiling to Bottom of Fan Blade:
11.73
Dim B Angled Ceiling To Bottom Of Fan Blade:
44.73
Dim B Flush Ceiling To Bottom Of Fan Blade:
10.73
Dim B Standard Ceiling To Bottom Of Fan Blade:
11.73
Dim C - Standard - Ceiling to Bottom of Canopy:
2.75
Dim C Standard Ceiling To Bottom Of Canopy:
2.75
Dim D - Standard - Width of Fan Body:
12.41
Dim D Standard Width Of Fan Body:
12.41
Dim E - Standard - Canopy Width:
6.49
Dim E Standard Canopy Width:
6.49
Dim G - Standard - Height of Motor Housing:
5.3
Dim G Standard Height Of Motor Housing:
5.30
Dips on Receiver:
No
Downrod Feature:
Includes 3'' and 2'' downrods to ensure proper distance from the ceiling and optimize air movement at your preferred blade height
Dry Rated:
Yes
Estimated Yearly Energy Cost:
12
ETL Approved:
Yes
Five Minute Fan:
No
Housing Feature:
Cottage White finish
Housing Finish:
Cottage White
LED Indicator on Transmitter:
No
LED Light Kit:
No
Light Spec:
No Light Kit Included
Location Feature:
Rated for indoor spaces only
Motor Type Feature:
Reversible, 4-speed Direct Drive™ motor provides unparalleled power, silent performance, and reliability over decades of daily use
Mounting Options:
Installer's Choice® three position mounting system allows for standard, low or angled mounting
Mounting Options Friendly Value:
Installer's Choice® three position mounting system allows for standard, low or angled mounting
No Light Cap Included:
No
No-Light Cap Included:
No
Number of Blades:
5
Pop Lock Blades:
No
Pop-Lock Blades:
No
Product Portfolio:
Casablanca
Pull Chain Feature:
Includes pull chains for quick and easy on/off and speed adjustments
Receiver Included:
No
Reversable Motor:
Yes
Reversible Blades:
Yes
Reversible Motor:
Reversible motor allows you to change the direction of your fan from downdraft mode during the summer which helps cool the room to updraft mode during the winter to help circulate trapped warm air near the ceiling.
RPM High:
174
RPM Low:
37
RPM Medium:
131
RPM Medum:
131
Safety Rating:
ETL
Serenity Speed Feature:
Extra low serenity speed produces a uniquely soothing breeze, while graceful blade movement creates a luxurious look and mood
Shipping Cubic Feet:
1.63
SIMPLEconnect:
No
Softlights:
No
Speeds:
4
Speeds Feature:
4 Speeds
Stainless Steel Hardware:
No
Sure Speed:
No
SureSpeed:
No
Tunable White:
No
Twist Lock Glass:
No
Ultra Low Profile:
No
Uplight Downlight Separate Control:
No
Warranty Feature:
Limited Lifetime Motor Warranty is backed by the only company with over 130 years in the fan business
13 degree blade pitch optimized to ensure ideal air movement and peak performance
4 Speeds
5 Cottage White blades included
Cottage White finish
Extra low serenity speed produces a uniquely soothing breeze, while graceful blade movement creates a luxurious look and mood
Includes 3'' and 2'' downrods to ensure proper distance from the ceiling and optimize air movement at your preferred blade height
Includes pull chains for quick and easy on/off and speed adjustments
Installer's Choice® three position mounting system allows for standard, low or angled mounting
Installer's Choice® three-position mounting system allows for standard, low, or angled mounting
Limited Lifetime Motor Warranty is backed by the only company with over 130 years in the fan business
Rated for indoor spaces only
Reversible motor allows you to change the direction of your fan from downdraft mode during the summer which helps cool the room to updraft mode during the winter to help circulate trapped warm air near the ceiling.
Reversible, 4-speed Direct Drive™ motor provides unparalleled power, silent performance, and reliability over decades of daily use
